What is the FANUC CRX cobot palletizer?

The FANUC CRX cobot palletizer is a collaborative robot palletizing system that operates without safety fencing, runs on 120V standard power, and is programmed by hand guidance or drag-and-drop tablet interface. It is ideal for manufacturers adding automation for the first time. Robot Palletizer LLC is a certified FANUC CRX integrator offering turnkey packages.

Does the FANUC CRX require a safety fence?

No. The FANUC CRX is a certified collaborative robot (cobot) that works safely alongside human operators without requiring a safety cage or fencing. This significantly reduces installation cost and floor space requirements compared to traditional industrial robots.

What power does the FANUC CRX palletizer require?

The FANUC CRX palletizer runs on standard 120V single-phase power. No special electrical infrastructure, high-voltage drops, or three-phase power upgrades are required, making it easy to deploy in existing facilities.

How much does a FANUC CRX palletizer cost?

Robot Palletizer LLC's FANUC CRX palletizer package RPFCRX30-1-2-CR starts at $94,750. This includes the FANUC CRX-30iA robot, end-of-arm tooling, controls, safety assessment, programming, and integration support.

What is the payload and reach of FANUC CRX models?

FANUC CRX models range from the CRX-10iA at 10 kg payload and 1,249 mm reach for light packaging, to the CRX-25iA at 30 kg payload and 1,889 mm reach for heavy end-of-line palletizing. The CRX-30iA offers 30 kg payload at 1,756 mm reach with wrist-button direct teaching.

Certified FANUC CRX Integrator · RPFCRX30-1-2-CR

Cobot Palletizing
Without the Cage

Name: RPFCRX30-1-2-CR FANUC CRX Cobot Palletizing System
Brand: Robot Palletizer LLC
Price: 94750 USD
Availability: InStock

The RPFCRX30-1-2-CR — our mobile cobot palletizing system powered by the FANUC CRX-30iA. No safety fence required, starts at $94,750, ships quickly from ARO.

The FANUC CRX cobot palletizer is a collaborative robot palletizing system that requires no safety fence, runs on standard 120V power, and can be programmed by hand guidance or tablet — no robot programming experience needed. Robot Palletizer LLC is a certified FANUC CRX integrator. Our RPFCRX30-1-2-CR package starts at $94,750 and includes the CRX-30iA robot, end-of-arm tooling, controls, and integration.

RPFCRX30-1-2-CR

Mobile Cobot
Palletizer System

The Model RPFCRX30-1-2-CR is a mobile cobot palletizing system powered by the versatile FANUC CRX-30iA collaborative robot. Designed for flexibility, mobility, and ease of use, this fully-automated system handles cases, bags, bottles, and pails — and can palletize up to two production lines simultaneously.

✓ No Safety Fence Required ✓ Mobile / Portable ✓ 8-Year Zero Maintenance ✓ Tablet Programming ✓ Dual-Line Capable ✓ Ships Quickly from ARO

Ease of operation is enhanced through FANUC's PalletTool® software, which generates optimized pallet patterns from product dimensions. Operators switch between unit loads at runtime — no computer required — with all pattern parameters saved for instant changeovers.

Request Quote for RPFCRX30-1-2-CR →

Watch It Work

CRX-30iA
Cobot Palletizing
in Action

Watch our RPFCRX30-1-2-CR system running — stacking cases with the FANUC CRX-30iA cobot arm, guided by PalletTool® software with no safety guarding required.

CRX-30iA arm stacking up to 66 lb payloads including EOAT

PalletTool® tablet interface — create and modify unit loads on the floor

Zero pressure product infeed conveyor — Itoh Denki MDR compatible

Up to two infeeds and two outfeeds — palletize two lines simultaneously

Book a Live Demo →

RPFCRX30-1-2-CR — FANUC CRX-30iA Cobot Palletizing System

System Features

What's Included
in Every System

The RPFCRX30-1-2-CR is a pre-engineered system — these features are standard. Additional options and custom configurations available on request.

FANUC CRX-30iA Robot — collaborative, no safety fence needed

R30iB Plus Mini Controller

Handles 1 case/pick — upgradeable to multiple cases

Rates up to 3 picks/min depending on product weight and pattern

Rates can be improved by adding Safety Scanners

FANUC PalletTool® Software — tablet-based, no computer required

Handles up to 66 lbs payload including End-of-Arm Tool

Slip/Tier-Sheet Rack included

Zero pressure product infeed conveyor (Itoh Denki MDR)

Up to two infeeds and two outfeeds — dual-line capable

Automatic Pallet Dispenser

Automatic Pallet Infeed & Outfeed

Options available: bags, trays, pails, and open cases

Automatic Stretch Wrappers — optional add-on

Full line integration service available

CRX-30iA Specifications

Robot Spec Sheet

FANUC CRX-30iA data sheet — payload, reach, and specifications

Specification	Value
Robot Model	FANUC CRX-30iA
Payload Capacity	30 kg (66 lbs) incl. EOAT
Reach	1,756 mm
Repeatability	±0.05 mm
System Starting Price	$94,750
Pick Rate	Up to 3 picks/min (upgradeable)
Infeeds / Outfeeds	Up to 2 / 2
Safety Fencing	Not required
Power Requirement	Standard 120V outlet
Maintenance Schedule	8-year zero scheduled maintenance
Programming	FANUC PalletTool® tablet interface
Mobility	Mobile / portable platform

Why Purchase a Palletizer Today?

The Business Case for
CRX Cobot Automation

🛡️

Protect Your Employees

Dramatically improve health and safety by eliminating repetitive heavy lifting at end-of-line. Reduce workers' comp costs and OSHA incidents to zero.

📦

Ship More, Ship Better

Build higher, more consistent pallet stacks — reducing shipping cube costs and delivering higher quality pallets to your customers every time.

📈

Increase Output

Increase output and throughput with consistent 24/7 operation — no fatigue, no call-outs, no production slowdowns from understaffing.

Full CRX Line

Not Sure Which
CRX is Right for You?

We'll help you select the right model for your payload, reach, and throughput requirements.

Model	Payload	Reach	Best Application	Notes
CRX-10iA	10 kg	1,249 mm	Light packaging, pick & place	Entry-level cobot
CRX-20iA/L	20 kg	1,418 mm	Mid-range palletizing, machine tending	Compact footprint
CRX-25iA	30 kg	1,889 mm	Heavy palletizing — longest reach	Top Pick
CRX-30iA ← This System	30 kg	1,756 mm	High payload, RPFCRX30-1-2-CR base	Featured

Help Me Choose the Right Model →

Ready to See the CRX-30iA Running?

Book a live demo at our Dallas facility or via virtual walkthrough. Call 1-888-567-6585 or submit a quote request and we'll respond within one business day.

Get a Quote — $94,750 Starting → 📞 1-888-567-6585
