RPF140-1-1-SW Automatic Robot Palletizer

Automatic Robot Palletizer

Fanuc Robot Palletizer RPF140-1-1

Ideally suited for high-volume production in bag and box palletizing operations, the new M-410iB/140H is the latest member of the M-410iB family of palletizing robots. It features a 140kg payload and a slim arm and wrist design with integrated cable routing to minimize interference with tooling and other peripheral devices. A compact size allows it to work in small spaces with low ceiling heights.

  • Achieves palletizing speeds up to 1900 cycles per hour (bags or boxes)
  • Compact wrist minimizes interference with peripheral devices
  • Integrated cable routing speeds up system installation and avoids cable snags
  • Compact design allows installation into low-ceiling factories and tight work spaces
  • Proven, reliable FANUC servo drives highest uptime and productivity
  • Able to operate in environments ranging from harsh to traditional factory floor
  • Can be mounted on the floor or a platform/riser
  • Operates with the company’s latest R-30iA controller with integrated intelligent functions such as iRVision, Collision Guard, ROBOGUIDE, PalletTool and PalletPRO software


System Features

  • <<Fanuc 410iB 140H Robot
  • <<R30iB Controller
  • <<Pallet Rack
  • <<Infeed Product Conveyor
  • <<Strechwrapper
  • <<Rates up to 30 cpm depending on product weight and pattern
  • <<Handles up to 260 lbs Capacity including End-of-Arm-Tool


Available Options

  • <<Slip/Tiersheet Rack
  • <<Zero Pressure product infeed conveyor
  • <<Up to four infeeds and four outfeeds
  • <<Automatic Pallet Dispenser
  • <<Automatic Pallet Infeed &Outfeed
  • <<Options available to handle bags, trays pails and open cases.
  • <<Full line integration Service

RPF50-1-1-O/U Layout:
